| Image Sensor | 1/3” 2MP PS CMOS Image sensor (0.84667 cm) |
| Effective Pixels | 1920(H) x 1080(V), 2 Megapixels |
| S/N Ratio | ≥55dB |
| Minimum Illumination | Color: 0.05 lux@F1.7 B/W: 0.005 lux@F1.7 0 lux (IR/warm light on) |
| Focal Length | 2.8mm ~ 28 mm |
| White Balance | Auto; indoor; outdoor; tracking; manual; sodium lamp; natural light; street lamp |
| Focus Control | Auto/Semi-Auto/Manual |
| Angle of View | H: 90.7°–22.2°; V: 48.2°–12.6°; D: 107.6°–25.9° |
| Shutter Speed | 1/3 s–1/100,000 s |
| AGC Control | Auto / Manual |
| Back Light Compensation | BLC / HLC / DWDR |
| Optical Zoom | 10x |
| Pan Travel | Pan: 0° to 355° |
| DORI Distance | 206.6m(Detect) 82.6m(Observe) 41.3m(Recognize) 20.7m(Identify) |
| Tilt Travel | Tilt: -15° to +90° |
| Manual Speed | Pan: 0.1°/s–26°/s Tilt: 0.1°/s–17.5°/s |
| Presets | 300 |
| Preset Speed | Pan: 26°/s; Tilt: 17.5°/s |
| Day/Night: IR Cut Filter | Auto (ICR) / Color / B/W |
| Video Compression | Instastream; H.265; H.264; H.264B; MJPEG (Sub Stream 1) |
| Video Streaming | Main stream: 1080P/1.3MP/720P (1–25/30 fps) Sub stream 1: D1/CIF (1–25/30fps) |
| Motion Detection | Support |
| Audio Compression | G.711a; G.711Mu; G.726; AAC; MPEG2-Layer2; G722.1; G729; G723 |
| Audio Streaming | 1 channel (built-in Mic)/ 1 channel (built-in speaker) |
| Networking | RJ-45 (10/100 Base-T) |
| Event Trigger | Motion/tampering detection; audio detection; network disconnection detection; IP conflict detection; memory card state detection; memory space detection |
| IVS | Tripwire, Intrusion, Human Detection |
| Protocols | HTTP; HTTPS; TCP/IP; IPv4; RTSP; UDP; SMTP; NTP; DHCP; DNS; DDNS; IPv6; SSL; FTP; ARP; RTCP; RTP; IP Filter; RTMP; TCP, ONVIF (Profile S&T); CGI |
| IR Range | IR Range of 30Mtr. |
| Operating Temperature | -30 °C to 60 °C (–22 °F to +140 °F) |
| Smart Phone | iPhone, iPad, Android Phone |
| Humidity | ≤95% |
| Memory | FTP; Micro SD card (256 GB) |
| Weatherproof Standard | IP66; TVS 2000 V lightning proof; surge protection; voltage transient protection |
| Dimension | 271.7 mm × 165.5 mm × 140 mm |
| Power Source | 12 VDC, 1.5 A (±10%) PoE (802.3af) |
| Power Consumption | Basic: 2.5 W Max.: 12.95 W (illuminator) |
| Weight | 1.07 kg |
